5.0 Inch TFT Square Screen
This 5″, 800*480 resolution, full RGB color graphic TFT LCD module with a 120.2(W) * 75.3(H) ×2.55(D) mm outline size. The Digital interface is available. The 5.0" TFT LCD is available with a touch screen panel in either resistive or capacitive touch technology.
- Product Introduction
Product Details
This 5″, 800*480 resolution, full RGB color graphic TFT LCD module with a 120.2(W) * 75.3(H) ×2.55(D) mm outline size. The Digital interface is available. The 5.0" TFT LCD is available with a touch screen panel in either resistive or capacitive touch technology. All of our TFT displays are RoHS compliant. Buy with confidence, this TFT display module has a free technical support.
Key Features
-Module Name: ENH-TQ050AC01
-LCD Size: 5.0 inch
-Module Size: 120.2(W)x75.3(H)x2.55(D) mm
-Dot Pitch: 0.045(W)x0.135(H) mm
-Active Area: 108(W)x64.8(H) mm
-Driver element: a-Si TFT active matrix
-Resolution: 800x3(RGB)x480
-Display Mode: Normally White, Transmissive
-Interface: Digital
-Surface Treatment: Anti-Glare
-Color Arrangement: RGB-Stripe
-Power Voltage: VDD=3.0~3.6V
-Operation Temperature: -30℃~80℃
-Storage Temperature: -20℃~70℃
FAQ
1. Do you have MOQ?
A: No, we do not have MOQ.
2. When can I get the items?
A: It takes 5-7 working days for shipping samples. eneral speaking, all depend on order quantity and we will arrange to make production as soon as possible when order confirmed.
3. May I get some discount?
A: Sure. Discount is available for large order quantity.
